Service Page - PPS9A6B90/26

Tempered glass surface, Black

frameless design: install the hob either flush or slightly raised on the worktop

Cast iron pan supports with rubber feet

FlameSelect: precisely control and adjust the flame in nine defined levels.

Design co-ordinated control dials: easily access dials in front with strong grip for effortless turning.

Ignition via control dials: just push and turn the dials to ignite the flame.

5 gas burners:

Left: wok burner up to 4 KW (depending on gas type)

Center front: economy burner up to 1 KW (depending on gas type)

Center rear: standard burner up to 1.75 KW (depending on gas type)

Right rear: high-speed burner up to 3 KW (depending on gas type)

Right front: standard burner up to 1.75 KW (depending on gas type)

Flame failure safety device: prevents unwanted gas flow when flame goes out.

Usable for: Nat gas L/LL G25/20mbar(DE)
NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar

Pre-set for natural gas

Nozzle set for LPG jets included. Connection to 28-30/37 mbar bottled gas. Nozzles for all other gas types can be ordered via the customer service. For nozzle change, please contact the customer service.

Dimensions of the product (HxWxD mm): 58 x 915 x 520

Required niche size for installation (HxWxD mm) : 45 x 850 x (490 - 502)

Min. worktop thickness: 30 mm

Power cord: 1.5 m

Connected load: 11.5 KW
